What is the difference between a vertical carton erector and a horizontal carton erector?

Author : Chure

Update time : 2022-07-28 21:17:00

First, the efficiency is different. The biggest difference between these two kinds of carton erector is the difference in efficiency. Generally, vertical carton erector are also called medium-speed carton erector, while horizontal carton erector are called high-speed carton erector. The vertical carton erector generally has a stable speed of 12 cases/min. The general stable speed of the horizontal type is above 20 boxes/min.

Second, the storage tank volume is different. Generally, the storage capacity of the vertical carton erector is relatively small. If a normal 5-layer corrugated cardboard box is used, it can store about 60-70 pieces. The horizontal carton erector can store about 100 pieces, and the hopper bin of the horizontal carton erector can be enlarged, but the vertical type cannot.

Third, the space occupied is different. Due to its relatively small output, the vertical carton erector is an economical device, so it has a small size and a small footprint. However, as a high-speed carton erector, the horizontal carton erector occupies a large area. The area is relatively large, which is why the vertical carton erector is widely used.

Fourth, the storage methods are different. The vertical carton erector adopts a vertical storage mechanism, which has relatively high requirements on the quality of the carton; the horizontal carton erector lays the carton flat, and uses a suction cup to absorb the carton, which has very high requirements on the carton.

(Left: Vertical carton erector ;Right: Horizontal carton erector)

In terms of cost, the manufacturing cost of the horizontal carton erector is higher than that of the vertical carton erector, but whether it is vertical or horizontal, the fault point can be found through the touch screen and the fault can be easily eliminated, which is indispensable for modern enterprises to carry out automated large-scale production. Packaging equipment, especially in the current situation of the epidemic, a machine can help you solve the difficult situation of factory employment and is your right-hand man for delivery.
